Peristaltic Pump with Stainless Steel Housing

MP100B | MP300B | MP600B (Speed Variable Paristaltic Pump with 304 Stainless Steel Housing)

  • Easy to use LCD display for quick setup and clear indicators.
  • Delayed start/stop for flexible operation.
  • Start/stop, reverse flow, full-speed, speed control, and memory retention.
  • Analog speed control and isolated external signals for safety.
  • RS485 with MODBUS for easy, customizable integration.
  • Durable ABS body with sleek, ergonomic design.
  • Accurate time- and volume-based dispensing.
See More See Less

The Speed Variable peristaltic pumps are equipped with essential functionalities like start-stop capability, speed adjustment, bi-directional rotation, and feature a user-friendly LCD display. They also incorporate advanced options such as multi-segment dispensing and an anti-drop mechanism. Moreover, these pumps support RS485 communication via the MODBUS protocol, ensuring smooth integration with diverse equipment setups.

MP100B
Flow Rate : 0.00011-750 ml/min
Speed Rate : 0.1~150 RPM
Driver Weight : 3.5kg
Power Consumption : <40W		 MP300B
Flow Rate : 0.005-1750 ml/min
Speed Rate : 0.1~350 RPM
Driver Weight : 4.3kg
Power Consumption : <50W		 MP600B
Flow Rate : 0.005-3000 ml/min
Speed Rate : 0.1-600 RPM
Driver Weight : 4.3kg
Power Consumption : <60W

What’s in the Box: Speed Variable Peristaltic Pump with Stainless Steel Body

  • Peristaltic Pump
  • Pump Head
  • Foot Switch (optional)
  • Hand Dispenser (optional)
  • Instruction Manual
  • RS485 Connector
  • 2 Meter Compatible tube
  • Power Cord
Download Catalog Download Instruction Manual
Speed Resolution 0.1RPM (speed ≤ 100 RPM ) /1RPM (speed>100RPM)
Duration Running time 0.1~999 S/Min/H/D,
Interval time 0.1~999 S/Min/H/D
Dispensing Interval Time 0.1~999 S/Min/H/D
Dispensing Time 1~999, “0” Infinite cycle
External Control Signal Input (1) Start/Stop: passive contact, external control input level (5~24V)
(2) Forward/Reverse: passive contact, external control input level (5~24V)
(3) Speed Regulation: analog 0~5V, 0~10V, 4~20mA can be set
External Control signal output (1) Start/Stop: Level Signal (following input voltage)
(2) Forward/Reverse: Level Signal (following input voltage)
Working Environment Temperature 0 ~ 40°C, relative humidity<80%
IP Grade IP31
Dimension (L×W×H) 261mm x 150mm x 237mm
